A highly configurable specialist chair for higher dependency users
Mechanism
- 37 degrees of manual tilt-in-space and full-length compensating legrest
- 10 degrees of forward tilt available as an option
- Drop-down armrest available as an option to help with transfers and sling insertion
- Electric upgrade option
Size
Standard chair adjustment options:
- Adjust seat width from 350 mm (14”) to 550 mm (22”)
- Adjust seat depth from 400 mm (16”) to 550 mm (22”)
- Adjust seat height from 330 mm (13”) to 530 mm (21”)
- Weight capacity 160 kg (25 st)
Other size options are available on request.
Pressure management
- Pressure-reducing fabric and continuous overlay for thigh support
- Integrated self-supply overlay (fit your own pressure cushion)
- Lockable, reduced-shear backrest recline to maximise pelvic stability
Posture management
- Removable footplate with angle and height-adjustment options as standard
- External lateral supports available as an optional extra
- Postural backrest upgrade option to support more complex postural requirements
Measurements and specifications
- Overall chair width 700 mm (28”)
- Overall chair depth 1075 mm (42”)
- Overall chair height 1280 mm (50”)
- Overall chair depth with legs elevated 1550 mm (61”)
- Backrest angle 90° – 130°
- TIS angle:
- 7° – 37° (manual)
- 10° – 37° (electric)
- Fabric: Vinyl fabric with vapour-permeable (VP) fabric on all contact areas
